Mover

The Compact, Low-Frequency Direct-Drive/Inertial-Drive Transducer

Overview

The Mover is a patented low-frequency direct-drive/tactile transducer designed to kick the listener's butt. Adaptable to various purposes, including 4D cinemas, theme parks, or venues with vibrating acoustic floors — as well as applications that go beyond entertainment — Mover lets audiences feel the sound through haptic perception by vibrating the surrounding environment, which the human body picks up and, through bone conduction, stimulates the inner ear, translating the vibrations into perceivable frequencies.

And despite its compact design, Mover packs a wallop, providing both scalability and miniaturization, depending on the setup. Featuring an external coupler that lets users connect its moving mass to the receiving surface, Mover can be used in direct-drive applications in which the transducer is anchored to an immovable surface and the moving magnet is connected to a movable surface, such as a floating floor or a chair, to produce dramatic effects with extraordinary efficiency.

Features

  • Very high power tactile transducer.
  • High efficiency.
  • High mechanical power.
  • High-quality magnet
  • Very high ratio between moving mass and total mass.
  • Compact design.
  • Ultra-Low frequency extension.
  • DC moving capabilities
  • No mounting plane limitations.
  • Adaptable for various purposes.
  • Two versions available with different impedances, depending on usage conditions.
  • External coupler allows to connect the transducer’s moving mass to the receiving surface.
  • Thermal protection: internal thermal switch.

Specifications

General
Construction Mover ID
Dimensions (L x H x W)90 mm x 90 mm x 90 mm (3.5 in x 3.5 in x 3.5 in)
Construction Mover DD
Dimensions (L x H x W)90 mm x 116 mm x 90 mm (3.54 in x 4.57 in x 3.54 in)
Weight2.44 kg (4.4 lb)
