M-Drive

The High-Power Solution for Lo-Z OEM Loudspeaker Applications

Powersoft_ICONS_features-black_Fixed-Switch-Freq Powersoft_ICONS_features-black_SRM Powersoft_ICONS_features-black_PFC Powersoft_ICONS_features-black_DPC-patented Powersoft_ICONS_features-black_DSP-optional GreenPower@2x

Overview

The M-Drive amplifier module is specifically designed to drive the Powersoft M-Force transducer. Featuring Powersoft's patented Smart Rails Management (SRM) technology, the M-Drive maximizes system efficiency and reduces power consumption in any load condition, ensuring reliable performance in any OEM loudspeaker system.

Compatible with all Powersoft DSP solutions, including the ArmoníaPlus, the M-Drive amp module can be tailored to fit any system, providing OEM applications with powerful and flexible signal processing tools while ensuring remarkable infrasonic reproduction. In addition, the M-Drive offers optional pairing with Powersoft DPC® technology for complete control over the sonic performance of the entire system.

MyPowersoft services are available for this product

Features

  • Efficient and robust
  • Specifically designed to drive M-Force® transducer
  • Maximize performances, minimize consumption:
  • Patented SRM (Smart Rails Management) technology allows to maximize the efficiency of the system and drastically reducing power consumption at any load condition.
  • Complete set of protections
  • Powerful and flexible signal processing tools
  • Thanks to the compatiblity with all Powersoft DSP solutions, performances can be easily tailored to fit your deseign with Armonía Pro Audio Suite™.
  • Compatible with Powersoft DPC® technology for complete control over the sonic performance of the whole system regardless of acoustic load.

Specifications

General
Output power in single-channel mode
Single-Ended Mode (SE)4930 W @ 8 Ω9167 W @ 4 Ω14970 W @ 2 Ω
Max output voltage / current
Single-Ended Mode (SE)310 Vpeak / 200 Apeak
AC main power
Power supplyUniversal, regulated switch mode with PFC (Power Factor Correction)
Rated Power Supply Voltage100-240 V ±10%, 50-60 Hz
Operating Voltage90 V – 264 V
Average power consumption1500 W
PROCESSING
EqualizerParametric equalizers: peaking, hi/lo-shelving, all-pass, band-pass, band-stop, hi/lo-pass
CrossoverButterworth, Linkwitz-Riley, Bessel: 6 dB/oct to 48 dB/oct (IIR)
Limiters and protectionsExcursion limiter, current& power limiter, current clamp, clip limiter, Brownout limiter, thermal

Applications examples
