I servizi MyPowersoft sono disponibili per questo prodotto. Plenum Mount AC Adapter Più Informazioni Flessibilità di montaggio Auto-setup Power sharing Totalmente controllabile in remoto tramite sistemi di terze parti General Output power per channel Output power per channel 160 W @ 2 Ω 160 W @ 4 Ω 160 W @ 8 Ω Maximum power-sharing capacity per channel 320 W @ 4 Ω 320 W @ 8 Ω Max output voltage / current Maximum unclipped output voltage 142 Vpeak Maximum output current 15. 6 Apeak AC main power Power supply Universal, regulated switch mode with PFC (Power Factor Correction) Nominal power requirement 100-240 V ±10%, 50-60 Hz Operating voltage 90 V - 264 V Power consumption/current draw Idle 115 V: 11 W - 0. 21 A 230 V: 12 W - 0. 17 A 1/8 of max output power @ 4 Ω 115 V: 73 W - 0. 67 A 230 V: 75 W - 0.
Progettato per non fermarsi
Powersoft’s DSP implements a complete audio management system that provides a unique level of control and can be used to set the tone of any space.
Controlling and monitoring of a Powersoft amplifier can be done through ArmoníaPlus.
Power Sharing enables part of the power to be shared across all output channels so that it can be used where it is needed the most.
Our current line of amplifier offers Dante™ either as standard or as an option on any model, for audio over IP networking.
Serie MEZZO - all models
| Model | Total power | Per channel | Channels | Form factor | AoIP |
|---|---|---|---|---|---|
| MEZZO 604 A+ | 600 W | 150 W @ 2 Ω 150 W @ 4 Ω 150 W @ 8 Ω | 4 | - | Dante / AES67 |
| MEZZO 324 A+ | 320 W | 80 W @ 2 Ω 80 W @ 4 Ω 80 W @ 8 Ω | 4 | - | Dante / AES67 |
| MEZZO 602 A+ | 600 W | 200 W @ 2 Ω 300 W @ 4 Ω 300 W @ 8 Ω | 2 | - | Dante / AES67 |
| MEZZO 322 A+ | 320 W | 160 W @ 2 Ω 160 W @ 4 Ω 160 W @ 8 Ω | 2 | - | Dante / AES67 |
| MEZZO 602 A | 600 W | 200 W @ 2 Ω 300 W @ 4 Ω 300 W @ 8 Ω | 2 | - | - |
| MEZZO 602 AD | 600 W | 200 W @ 2 Ω 300 W @ 4 Ω 300 W @ 8 Ω | 2 | - | Dante / AES67 |
| MEZZO 604 AD | 600 W | 150 W @ 2 Ω 150 W @ 4 Ω 150 W @ 8 Ω | 4 | - | Dante / AES67 |
| MEZZO 604 A | 600 W | 150 W @ 2 Ω 150 W @ 4 Ω 150 W @ 8 Ω | 4 | - | - |
| MEZZO 324 AD | 320 W | 80 W @ 2 Ω 80 W @ 4 Ω 80 W @ 8 Ω | 4 | - | Dante / AES67 |
| MEZZO 324 A | 320 W | 80 W @ 2 Ω 80 W @ 4 Ω 80 W @ 8 Ω | 4 | - | - |
| MEZZO 322 AD | 320 W | 160 W @ 2 Ω 160 W @ 4 Ω 160 W @ 8 Ω | 2 | - | Dante / AES67 |
| MEZZO 322 A | 320 W | 160 W @ 2 Ω 160 W @ 4 Ω 160 W @ 8 Ω | 2 | - | - |
Funzionalità
- Multiple mounting options
- Auto-Setup
- Power-sharing
- Full remote control via 3rd party controls
Specifiche
| Output power per channel | |||
|---|---|---|---|
| Output power per channel | 160 W @ 2 Ω | 160 W @ 4 Ω | 160 W @ 8 Ω |
| Maximum power-sharing capacity per channel | 320 W @ 4 Ω | 320 W @ 8 Ω | |
| Max output voltage / current | |||
| Maximum unclipped output voltage | 142 Vpeak | ||
| Maximum output current | 15.6 Apeak | ||
| AC main power | |||
| Power supply | Universal, regulated switch mode with PFC (Power Factor Correction) | ||
| Nominal power requirement | 100-240 V ±10%, 50-60 Hz | ||
| Operating voltage | 90 V - 264 V | ||
| Power consumption/current draw | |||
| Idle | 115 V: 11 W - 0.21 A | 230 V: 12 W - 0.17 A | |
| 1/8 of max output power @ 4 Ω | 115 V: 73 W - 0.67 A | 230 V: 75 W - 0.41 A | |
| Thermal dissipation* | |||
| Idle | 115 V: 38 BTU/h | 230 V: 40 BTU/h | |
| 1/8 of max output power @ 4 Ω | 115 V: 78 BTU/h | 230 V: 91 BTU/h | |
