| General | |||
| Output power in single channel mode | |||
| Single channel mode | 500 W @ 2 Ω | 260 W @ 4 Ω | 130 W @ 8 Ω |
| Bridge mode | 1000 W @ 8 Ω | 520 W @ 16 Ω | |
| Max output voltage / current | |||
| Single channel mode | 72 Vpeak / 28 Apeak | ||
| Bridge mode | |||
| AC main power | |||
| Power supply | Universal, regulated switch mode | ||
| Nominal power requirement | 100-240 V ±10%, 50-60 Hz | ||
| Operating voltage | 90 V – 264 V | ||
| Power consuption | |||
| Idle | |||
| 1/8 of max output power @ 4 Ω | |||
| 1/4 of max output power @ 4 Ω | |||
| THERMAL | |||
| Operating temperature range | 0° – 45° C – 32° – 113° F | ||
| Thermal dissipation* | |||
| Idle | |||
| 1/8 of max output power @ 4 Ω | 115 V: 150 BTU/h – 37.8 kcal/h | 230 V: 150 BTU/h – 37.8 kcal/h | |
| 1/4 of max output power @ 4 Ω | 115 V: 246 BTU/h – 62.8 kcal/h | 230 V: 246 BTU/h – 62.0 kcal/h | |
The new ProNet485 is a small device, hardly larger than a network adapter, specifically designed to make most Powersoft DSP-equipped modules Armonía compatible. It allows direct connection and communication between the DSP-equipped module and any PC running Windows operating systems and Armonía. The connection between the ProNet485 and the computer is done via an RJ45 to RS485 […]
The USB to RS485 provides direct connection and communication between the DSP-equipped module or amplifier and any PC running Windows operating systems and ArmoníaPlus. It works in conjunction with the ProNet485 adapter.
There are two types of heatsink, namely “Medium” and “Large”. The former is compatible with the following DigiModmodules: 2004PFC2, 2000HV, 1500, 1000 and 500. The “Medium” heatsink is realised, just like its bigger counterpart, as plain alumium plate which guarantees proper heat dissipation to the compatible DigiMod amplifier. Moreover, the heatsink comes with already assembled in/out Powercons connectors, that ensure high current […]
The new ProNet485 is a small device, hardly larger than a network adapter, specifically designed to make most Powersoft DSP-equipped modules Armonía compatible. It allows direct connection and communication between the DSP-equipped module and any PC running Windows operating systems and Armonía. The connection between the ProNet485 and the computer is done via an RJ45 to RS485 cable and an RS485-USB adapter. The ProNet485 has an external ABS shell that can be easily removed to expose the internal PCB. This tiny board can be mounted inside your Powersoft powered products to activate all ProNet485 features permanently. The ProNet485 has two sides
The USB to RS485 provides direct connection and communication between the DSP-equipped module or amplifier and any PC running Windows operating systems and ArmoníaPlus. It works in conjunction with the ProNet485 adapter.
There are two types of heatsink, namely "Medium" and "Large". The former is compatible with the following DigiModmodules: 2004PFC2, 2000HV, 1500, 1000 and 500. The “Medium” heatsink is realised, just like its bigger counterpart, as plain alumium plate which guarantees proper heat dissipation to the compatible DigiMod amplifier. Moreover, the heatsink comes with already assembled in/out Powercons connectors, that ensure high current capacity and locking action for safe operation.
